AUXILIARY ELECTRIC HEATER KITS CHARACTERISTICS AND APPLICATION
*For Canadian use only. Uses “P” fuses for inductive circuit.
+Field Installed Only
208-240 VOLT, THREE PHASE, 60 HZ, AUXILIARY ELECTRIC HEATER KITS CHARACTERISTICS AND APPLICATION
Single Power Supply For Both Unit And Heater Kit
Separate Power Supply For Both Unit And Heater Kit
Unit
Model
Number
RJNL-
RXJJ-
Heater Kit
Nominal kW
No. of
Sequence
Steps
Rated Heater
kW @
208/240 V
Heater
KBTU/Hr @
208/240 V
Heater
Amp. @
208/240 V
Unit Min. Ckt
Ampacity @
208-240V
Min/Max
@ 208 V
Min/Max
@240 V
Over Current
Protective Device Size
Min. Ckt.
Ampacity
208/240V
Max. Fuse
Size
208/240V
Min. Circuit
Ampacity
208/240V
Min/Max
@ 208 V
Min/Max
@ 240 V
Over Current
Protective Device Size
No Heat — — — — 34/34 40/50 40/50 — — 34/34 40/50 40/50
A15C 1 10.8/14.4 36.84/49.13 30.1/34.7 72/78 80/80 80/80 38/44 40/45 — — —
A20C 1 14.4/19.2 49.13/65.5 40.1/46.2 85/92 90/90 100/100 51/58 60/60 — — —
A24C 1 18/24 61.41/81.88 50.1/57.8 97/107 100/100 110/110 63/73 70/80 — — —
No Heat — — — — 34/34 40/50 40/50 — — 34/34 40/50 40/50
A15C 1 10.8/14.4 36.84/49.13 30.1/34.7 72/78 80/80 80/80 38/44 40/45 — — —
A20C 1 14.4/19.2 49.13/65.5 40.1/46.2 85/92 90/90 100/100 51/58 60/60 — — —
A24C 1 18/24 61.41/81.88 50.1/57.8 97/107 100/100 110/110 63/73 70/80 — — —
A072CL
A072CM
Heater Kit
Heat Pump
Heater Kit
Heat Pump
A072DL
A072DM
480 VOLT, THREE PHASE, 60 HZ, AUXILIARY ELECTRIC HEATER KITS CHARACTERISTICS AND APPLICATION
No Heat — — — — 17 20/25 — — — 17 20/25 —
A15D 1 14.4 49.13 17.4 39 45/45 — 22 25 — — —
A20D 1 19.2 65.5 23.3 47 50/50 — 30 30 — — —
A24D 1 24 81.88 28.9 54 60/60 — 37 40 — — —
No Heat — — — — 17 20/25 — — — 17 20/25 —
A15D 1 14.4 49.13 17.4 39 45/45 — 22 25 — — —
A20D 1 19.2 65.5 23.3 47 50/50 — 30 30 — — —
A24D 1 24 81.88 28.9 54 60/60 — 37 40 — — —
A072YL
600 VOLT, THREE PHASE, 60 HZ, AUXILIARY ELECTRIC HEATER KITS CHARACTERISTICS AND APPLICATION
No Heat — — — — 14 15/20 — — — 14 15/20 —
A15Y 1 14.4 49.13 13.9 32 35/35 — 18 20 — — — A20Y 1 19.2 65.5 18.8 38 40/40 — 24 25 — — — A24Y 1 24 81.88 23.1 43 45/45 — 29 30 — — —
