Rheem RKKL Series User Manual

10
Model RKKL-Series B090CL15E B090CL22E B090CM15E B090CM22E
Cooling Performance
1
Gross Cooling Capacity Btu [kW] 87,000 [25.49] 87,000 [25.49] 87,000 [25.49] 87,000 [25.49]
EER/SEER
2
11.2/NA 11.2/NA 11.2/NA 11.2/NA
Nominal CFM/AHRI Rated CFM [L/s] 2800/2925 [1321/1380] 2800/2925 [1321/1380] 2800/2925 [1321/1380] 2800/2925 [1321/1380]
ARI Net Cooling Capacity Btu [kW] 84,000 [24.61] 84,000 [24.61] 84,000 [24.61] 84,000 [24.61]
Net Sensible Capacity Btu [kW] 64,800 [18.99] 64,800 [18.99] 64,800 [18.99] 64,800 [18.99]
Net Latent Capacity Btu [kW] 19,200 [5.63] 19,200 [5.63] 19,200 [5.63] 19,200 [5.63]
IEER
3
12.1 12.1 12.1 12.1
Net System Power kW 7.5 7.5 7.5 7.5
Heating Performance (Gas)
4
Heating Input Btu [kW] (1st Stage / 2nd Stage) 75,000/150,000 [21.97/43.95] 75,000/150,000 [21.97/43.95] 75,000/150,000 [21.97/43.95] 75,000/150,000 [21.97/43.95]
Heating Output Btu [kW] (1st Stage / 2nd Stage) 60,750/121,500 [17.8/35.6] 91,125/182,250 [26.7/53.4] 60,750/121,500 [17.8/35.6] 91,125/182,250 [26.7/53.4]
Temperature Rise Range °F [°C] (1st Stage / 2nd Stage) 0-0 [0-0] / 25-55 [13.9-30.6] 0-0 [0-0] / 40-70 [22.2-38.9] 0-0 [0-0] / 25-55 [13.9-30.6] 0-0 [0-0] / 25-55 [22.2-38.9]
Steady State Efficiency (%) 81 81 81 81
No. Burners 6969
No. Stages 2222
Gas Connection Pipe Size in. [mm] 0.5 [12.7] 0.75 [19.05] 0.5 [12.7] 0.75 [19]
Compressor
No./Type 1/Scroll 1/Scroll 1/Scroll 1/Scroll
Outdoor Sound Rating (dB)
5
88 88 88 88
Outdoor Coil - Fin Type Louvered Louvered Louvered Louvered
Tube Type MicroChannel MicroChannel MicroChannel MicroChannel
MicroChannel Depth in. [mm] 1 [25.4] 1 [25.4] 1 [25.4] 1 [25.4]
Face Area sq. ft. [sq. m] 13.5 [1.25] 13.5 [1.25] 13.5 [1.25] 13.5 [1.25]
Rows / FPI [FPcm] 1 / 23 [9] 1 / 23 [9] 1 / 23 [9] 1 / 23 [9]
Indoor Coil - Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 13.5 [1.25] 13.5 [1.25] 13.5 [1.25] 13.5 [1.25]
Rows / FPI [FPcm] 2 / 18 [7] 2 / 18 [7] 2 / 18 [7] 2 / 18 [7]
Refrigerant Control Orifices Orifices Orifices Orifices
Drain Connection No./Size in. [mm] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4]
Outdoor Fan - Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6] 1/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 4500 [2124] 4500 [2124] 4500 [2124] 4500 [2124]
No. Motors/HP 1 at 1/2 HP 1 at 1/2 HP 1 at 1/2 HP 1 at 1/2 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan - Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/15x15 [381x381] 1/15x15 [381x381] 1/15x15 [381x381] 1/15x15 [381x381]
Drive Type/No. Speeds Belt/Variable Belt/Variable Belt/Variable Belt/Variable
No. Motors 1111
Motor HP 2222
Motor RPM 1725 1725 1725 1725
Motor Frame Size 56 56 56 56
Filter - Type Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(NO.) Size Recommended in. [mm x mm x mm] (6)2x18x18 [51x457x457] (6)2x18x18 [51x457x457] (6)2x18x18 [51x457x457] (6)2x18x18 [51x457x457]
Refrigerant Charge Oz. [g] 117.6 [3334] 117.6 [3334] 117.6 [3334] 117.6 [3334]
Weights
Net Weights lbs. [kg] 882 [400] 918 [416] 882 [400] 918 [416]
Ship Weights lbs. [kg] 919 [417] 955 [433] 919 [417] 955 [433]
CONTINUED
GENERAL DATA - RKKL MODELS
NOM. SIZES 7.5, 10 AND 12.5 TON [26.4, 35.2 AND 44.0 kW]

Rheem RKKL Series Specifications

General

Brand	Rheem
Model	RKKL Series
Category	Air Conditioner
Language	English
