Model RKKL-Series B151DM15E B151DM25E B151YL25E B151YM25E
Cooling Performance
1
Gross Cooling Capacity Btu [kW] 156,000 [45.71] 156,000 [45.71] 156,000 [45.71] 156,000 [45.71]
EER/SEER
2
11.1/NA 11.1/NA 11.1/NA 11.1/NA
Nominal CFM/AHRI Rated CFM [L/s] 5000/4225 [2360/1994] 5000/4225 [2360/1994] 5000/4225 [2360/1994] 5000/4225 [2360/1994]
ARI Net Cooling Capacity Btu [kW] 150,000 [43.95] 150,000 [43.95] 150,000 [43.95] 150,000 [43.95]
Net Sensible Capacity Btu [kW] 106,600 [31.23] 106,600 [31.23] 106,600 [31.23] 106,600 [31.23]
Net Latent Capacity Btu [kW] 43,400 [12.72] 43,400 [12.72] 43,400 [12.72] 43,400 [12.72]
IEER
3
10.8 10.8 10.8 10.8
Net System Power kW 13.54 13.54 13.54 13.54
Heating Performance (Gas)
4
Heating Input Btu [kW] (1st Stage / 2nd Stage) 75,000/150,000 [21.97/43.95] 126,000/252,000 [36.92/73.84] 126,000/252,000 [36.92/73.84] 126,000/252,000 [36.92/73.84]
Heating Output Btu [kW] (1st Stage / 2nd Stage) 60,750/121,500 [17.8/35.6] 102,000/204,000 [29.89/59.77] 102,000/204,000 [29.89/59.77] 102,000/204,000 [29.89/59.77]
Temperature Rise Range °F [°C] (1st Stage / 2nd Stage) 15-45 [8.3-25] / 15-45 [8.3-25] 25-55 [13.9-30.6] / 25-55 [13.9-30.6] 25-55 [13.9-30.6] / 25-55 [13.9-30.6] 25-55 [13.9-30.6] / 25-55 [13.9-30.6]
Steady State Efficiency (%) 81 81 81 81
No. Burners 6999
No. Stages 2222
Gas Connection Pipe Size in. [mm] 0.5 [12.7] 0.75 [19] 0.75 [19] 0.75 [19]
Compressor
No./Type 2/Scroll 2/Scroll 2/Scroll 2/Scroll
Outdoor Sound Rating (dB)
5
88 88 88 88
Outdoor Coil - Fin Type Louvered Louvered Louvered Louvered
Tube Type MicroChannel MicroChannel MicroChannel MicroChannel
MicroChannel Depth in. [mm] 1 [25.4] 1 [25.4] 1 [25.4] 1 [25.4]
Face Area sq. ft. [sq. m] 27 [2.51] 27 [2.51] 27 [2.51] 27 [2.51]
Rows / FPI [FPcm] 2 / 23 [9] 2 / 23 [9] 2 / 23 [9] 2 / 23 [9]
Indoor Coil - Fin Type Louvered Louvered Louvered Louvered
Tube Type Rifled Rifled Rifled Rifled
Tube Size in. [mm] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5] 0.375 [9.5]
Face Area sq. ft. [sq. m] 13.5 [1.25] 13.5 [1.25] 13.5 [1.25] 13.5 [1.25]
Rows / FPI [FPcm] 4 / 15 [6] 4 / 15 [6] 4 / 15 [6] 4 / 15 [6]
Refrigerant Control TX Valves TX Valves TX Valves TX Valves
Drain Connection No./Size in. [mm] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4] 1/1 [25.4]
Outdoor Fan - Type Propeller Propeller Propeller Propeller
No. Used/Diameter in. [mm] 2/24 [609.6] 2/24 [609.6] 2/24 [609.6] 2/24 [609.6]
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct/1
CFM [L/s] 8000 [3775] 8000 [3775] 8000 [3775] 8000 [3775]
No. Motors/HP 2 at 1/2 HP 2 at 1/2 HP 2 at 1/2 HP 2 at 1/2 HP
Motor RPM 1075 1075 1075 1075
Indoor Fan - Type FC Centrifugal FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter in. [mm] 1/15x15 [381x381] 1/15x15 [381x381] 1/15x15 [381x381] 1/15x15 [381x381]
Drive Type/No. Speeds Belt/Variable Belt/Variable Belt/Variable Belt/Variable
No. Motors 1111
Motor HP 5535
Motor RPM 1725 1725 1725 1725
Motor Frame Size 184 184 56 184
Filter - Type Disposable Disposable Disposable Disposable
Furnished Yes Yes Yes Yes
(NO.) Size Recommended in. [mm x mm x mm] (6)2x18x18 [51x457x457] (6)2x18x18 [51x457x457] (6)2x18x18 [51x457x457] (6)2x18x18 [51x457x457]
Refrigerant Charge Oz. [g] 147.2/152 [4173/4309] 147.2/152 [4173/4309] 147.2/152 [4173/4309] 147.2/152 [4173/4309]
Weights
Net Weights lbs. [kg] 1238 [562] 1274 [574] 1266 [574] 1274 [574]
Ship Weights lbs. [kg] 1275 [578] 1311 [595] 1303 [591] 1311 [595]
GENERAL DATA - RKKL MODELS
NOM. SIZES 7.5, 10 AND 12.5 TON [26.4, 35.2 AND 44.0 kW]

Rheem RKKL Series Specifications

General

Brand	Rheem
Model	RKKL Series
Category	Air Conditioner
Language	English
