ELECTRICAL DATA - RKNL (continued)
ELECTRICAL DATA - RLNL SERIES
B240YN/
C240YN
B241CL/
C241CL
B241CM/
C241CM/
B241CN/
C241CN/
B241DL/
C241DL/
B241DM/
C241DM/
B241DN/
C241DN/
B241YL/
C241YL
B241YM/
C241YM/
B241YN/
C241YN/
Unit Information
Unit Operating Voltage
Range
518-632 187-253 187-253 414-506 414-506 518-632 518-632
Volts
575 208/230 208/230 460 460 575 575
Minimum Circuit
Ampacity
42 95/95 103/103 49 52 37 39
Minimum Overcurrent
Protection Device Size
50 110/110 125/125 60 60 40 45
Maximum Overcurrent
Protection Device Size
50 110/110 125/125 60 60 45 50
Compressor Motor
No.
2 2 2 2 2 2 2
Volts
575 200/230 200/230 460 460 575 575
Phase
3 3 3 3 3 3 3
RPM
3450 3450 3450 3450 3450 3450 3450
HP, Compressor 1
10 10 10 10 10 10 10
Amps (RLA), Comp. 1
12.8 30.1/30.1 30.1/30.1 16.7 16.7 12.2 12.2
Amps (LRA), Comp. 1
80 225/225 225/225 114 114 80 80
HP, Compressor 2
7 1/2 7 1/2 7 1/2 7 1/2 7 1/2 7 1/2 7 1/2
Amps (RLA), Comp. 2
12.2 27.6/27.6 27.6/27.6 12.8 12.8 9.6 9.6
Amps (LRA), Comp. 2
80 191/191 191/191 100 100 78 78
Condenser Motor
No.
6 6 6 6 6 6 6
Volts
575 208/230 208/230 460 460 575 575
Phase
1 1 1 1 1 1 1
HP
1/3 1/3 1/3 1/3 1/3 1/3 1/3
Amps (FLA, each)
1 2.4/2.4/ 2.4/2.4 1.4 1.4 1 1
Amps (LRA, each)
1.8 4.7/4./ 4.7/4.7 2.4 2.4 1.8 1.8
Evaporator Fan
No.
1 1 1 1 1 1 1
Volts
575 208/230 208/230 460 460 575 575
Phase
3 3 3 3 3 3 3
HP
7 1/2 5 7 1/2 5 7 1/2 5 7 1/2
Amps (FLA, each)
7.8 14.7/14.7 23.1/23.1 6.6 9.6 5.3 7.8
Amps (LRA, each)
53.8 82.6/82.6 136/136 46.3 67 39.4 53.8
