ELECTRICAL DATA - RKNL (continued)
ELECTRICAL DATA - RLNL SERIES
B300CL/
C300CL/
H300CR
B300CM/
C300CM/
H300CS
B300DL/
C300DL/
H300DR
B300DM/
C300DM/
H300DS
B300YL/
C300YL
B300YM/
C300YM
Unit Information
Unit Operating Voltage
Range
187-253 187-253 414-506 414-506 518-632 518-632
Volts
208/230 208/230 460 460 575 575
Minimum Circuit
Ampacity
147/147 149/149 60 63 47 50
Minimum Overcurrent
Protection Device Size
175/175 175/175 70 70 60 60
Maximum Overcurrent
Protection Device Size
175/175 175/175 70 80 60 60
Compressor Motor
No.
2 2 2 2 2 2
Volts
200/240 200/240 460 460 575 575
Phase
3 3 3 3 3 3
RPM
3450 3450 3450 3450 3450 3450
HP, Compressor 1
11 1/2 11 1/2 11 1/2 11 1/2 11 1/2 11 1/2
Amps (RLA), Comp. 1
48.1/48.1 48.1/48.1 18.6 18.6 14.7 14.7
Amps (LRA), Comp. 1
245/245 245/245 125 125 100 100
HP, Compressor 2
11 1/2 11 1/2 11 1/2 11 1/2 11 1/2 11 1/2
Amps (RLA), Comp. 2
48.1/48.1 48.1/48.1 18.6 18.6 14.7 14.7
Amps (LRA), Comp. 2
245/245 245/245 125 125 100 100
Condenser Motor
No.
6 6 6 6 6 6
Volts
208/230 208/230 460 460 575 575
Phase
1 1 1 1 1 1
HP
1/3 1/3 1/3 1/3 1/3 1/3
Amps (FLA, each)
2.4/2.4 2/2 1.4 1.4 1 1
Amps (LRA, each)
4.7/4.7 3.9/3.9 2.4 2.4 1.8 1.8
Evaporator Fan
No.
1 1 1 1 1 1
Volts
208/230 208/230 460 460 575 575
Phase
3 3 3 3 3 3
HP
7 1/2 10 7 1/2 10 7 1/2 10
Amps (FLA, each)
24.2/24.2 28.5/28.5 9.6 12.5 7.8 10
Amps (LRA, each)
136/136 178/178 67 74.6 53.8 59.2
