ASSEMBLY
Front Rubber Fabric Deflectors (Standard Equipment)
Front Deflector (Figure AsmP-R-0064)
Attach the Front Deflector to the Mower with Bolts,
Flatwashers, and Locknuts.
Rear Metal Band - Figure AsmP-R-0063
Attach Deflectors to deck using 1/2” x 1-1/4” Bolts
and Locknuts (6). r.
