Originals

Original Sizes and Scanning Area/Missing Image Area

❖

Exposure glass

❖

Document feeder

Limitation

❒

Even if you correctly set originals in the document feeder or on the exposure

glass, 3mm, 0.1" margins on all four sides might not be copied.

A3A4

Horizontal size

Vertical size

Reference

position

Maximum Scanning area

A3 (297x420mm)

11"x17" (279x432mm)

CP01AEE
