227

Monitoring and Configuring the Printer

SNMP

The Ethernet interface includes the Simple Network Management Protocol (SNMP) agent for UDP and IPX.

Using the SNMP manager, you can obtain printer data.

The default community name is "public". Using this community name, you can obtain MIB data.

Supporting MIB (SNMP v1/v2)

MIB-II

PrinterMIB

HostResourceMIB

RicohPrivateMIB
