2. Enter " http://(the machine's IP address or host name)/" in the address bar.
When entering an IPv4 address, do not begin segments with zeros. For example: If the address is
"192.168.001.010", you must enter it as "192.168.1.10" to connect to the machine.
The top page of Web Image Monitor appears.
3. Click [Login].
The machine administrator can log on using the appropriate login user name and login password.
4. Click [Configuration], and then click [Logs] under Device Settings.
5. Select Collect Job Logs to specify Job Log settings, or select Collect Access Logs to specify
Access Log settings, and then select [Active].
6. Specify the recording levels for either Job Log Collect Level or Access Log Collect Level.
The settings shown for "Job Log Collect Settings Listed by Function Type" or "Access Log Collect Settings
Listed by Function Type" vary depending on the collection level selected.
If you change the setting in the list, the setting for Job Log Collect Level or Access Log Collect Level
automatically changes to [User Settings].
7. Click [OK].
Changes are also reflected in related log settings.
8. Click [Logout].
• The greater the Access Log Collect setting value, the more logs are collected.
Transfer Logs
Select to disable log transfer.
When log transfer is inactive, [Inactive] is displayed and this setting cannot be changed. When log transfer
is active, log records can be transferred to the log collection system.
1. Follow steps 1 to 4 in "Specify Log Collect Settings ".
2. Select [Inactive] under "Transfer Logs".
3. Click [OK].
4. Click [Logout].
Encrypt Logs
1. Follow steps 1 to 4 in "Specify Log Collect Settings ".
2. Select [Active] under "Encrypt Logs."
To disable log encryption, select [Inactive].
Managing Log Files
155
