Appendix
156
7
IEEE 1284 Interface Board Type A
❖ Transmission spec.:
IEEE 1284
❖ Required cable:
Standard IEEE 1284 compliant Micro Centronics 36 pin cable
IEEE 802.11b Interface Unit Type H
❖ Transmission spec.:
Based on IEEE 802.11b (wireless LAN)
❖ Protocol:
TCP/IP, IPX/SPX, AppleTalk
Note
❒ SmartDeviceMonitor and Web Image Monitor are supported.
❖ Data transfer speed:
Auto select from below speed
1 Mbps, 2 Mbps, 5.5 Mbps, 11 Mbps
❖ Frequency range:
• Inch version:
2412 - 2462 MHz (1 - 11 channels)
•Metric version:
2412 - 2472 MHz (1 - 13 channels)
❖ Transmittable distance:
1 Mbps 400 m
2 Mbps 270 m
5.5 Mbps 200 m
11 Mbps 140 m
Note
❒ These figures are a guideline for outdoor use. In general, the transmittable
distance indoors is 10 - 100 m, depending on environment.
❖ Transmission mode:
Ad hoc, and infrastructure mode
