Ricoh Aficio MP C3502 User Manual

19. Press [Exit].
If the connection test fails, check the settings, and then try again.
20. Press [OK].
21. Press [Exit].
22. Press the [User Tools/Counter] key.
Locating the SMB folder manually
1. Press [Change] under "Path".
2. Enter the path where the folder is located.
For example: if the name of the destination computer is "User", and the folder name is "Share", the
path will be \\User\Share.
If the network does not allow automatic obtaining of IP addresses, include the destination
computer’s IP address in the path. For example: if the IP address of the destination computer is
"192.168.0.191", and the folder name is "Share", the path will be \\192.168.0.191\Share.
3. Press [OK].
If the format of the entered path is not correct, a message appears. Press [Exit], and then enter the
path again.
Locating the SMB folder using Browse Network
1. Press [Browse Network].
The client computers sharing the same network as the machine appear.
Network display only lists client computers you are authorized to access.
2. Select the group that contains the destination computer.
3. Select the computer name of the destination computer.
Shared folders under it appear.
6. Scan
116

Ricoh Aficio MP C3502 Specifications

General

Print Technology	Laser
Print Speed	35 ppm
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Functions	Print, Copy, Scan, Fax
Duplex Printing	Yes
Memory (Standard)	1.5 GB
Hard Disk Drive	250 GB
Standard Paper Capacity	1, 200 sheets
Max Paper Capacity	4, 400 sheets
Connectivity	USB 2.0, Ethernet
Fax Transmission Speed	33.6 Kbps (optional)
Operating System Compatibility	Windows, Mac, Linux
Scan Resolution	600 dpi
