3. Paper guides
When loading paper in the bypass tray, align the paper guides flush against the paper.
4. Extender
Pull this extender out when loading sheets larger than A4 , 8
1
/
2
× 11 in the bypass tray.
5. Lower right cover
Open this cover when a paper jam occurs.
Rear and left view
1
1
1
CJS006
1. Ventilation holes
Prevent overheating.
2. Getting Started
32
