1. When the Machine Does
Not Operate As Wanted
This chapter explains basic troubleshooting procedures that are applicable to all
functions of this machine.
Indicators
This section explains the Indicators displayed when the machine requires the
user to remove misfed paper, to add paper or to perform other procedures.
x: Misfeed indicator Appears when a misfeed occurs.
See p.67 “Removing Jammed Paper”.
r: Add Paper indicator Appears when paper-out condition occurs.
See p.57 “Loading Paper”.
D: Add Toner indicator Appears when toner runs out.
See p.64 “Adding Toner”.
E: Waste Toner Full indicator Appears when the waste toner bottle is full.
Contact your sales or service representative.
L: Service Call indicator Appears when the machine is malfunctioning or requires
maintenance.
M: Open Cover indicator Appears when the front cover, etc., is open.
