Ricoh Aficio SP 204SN - Changing the IP Address Settings

13
3. Changing the IP Address Settings
Changing the IP Address Settings Using the Control Panel (SP
202SN/203SFN/204SFN/204SN only)
Configuring the Machine Settings to Obtain an IPv4 Address Automatically
1. Press the [User Tools] key.
2. Press the [
] or [ ] key to select [Network Settings], and then press the [OK] key.
3. Press the [
] or [ ] key to select [Machine IPv4 Address], and then press the [OK]
key.
4. Press the [ ] or [ ] key to select [DHCP Activated], and then press the [OK] key.
5. Make sure [DHCP Activated] is set to [On].
After a setting has been changed, the machine automatically reboots itself.
Configuring the Machine's IPv4 Address Manually
1. Press the [User Tools] key.
2. Press the [
] or [ ] key to select [Network Settings], and then press the [OK] key.
3. Press the [
] or [ ] key to select [Machine IPv4 Address], and then press the [OK]
key.
4. Press the [ ] or [ ] key to select [DHCP Activated], and then press the [OK] key.
