USB Cable Connection
For users outside the United States of America: properly shielded and grounded cables and
connectors must be used for connections to a host computer (and/or peripheral) in order to meet
emission limits.
For users in the United States of America: properly shielded and grounded cables and connectors
must be used for connections to a host computer (and/or peripheral) in order to meet FCC emission
limits.
USB connection is possible under Windows XP/Vista/7, Windows Server 2003/2003
R2/2008/2008 R2, and Mac OS X 10.3.3 or later.
A USB cable is not supplied with this printer. Select your cable according to the computer.
1. Connect the USB cable to the printer.
Connecting the USB cable to the standard USB port B
Connect the smaller connector of the USB cable to the standard USB port B on the left side of
the printer.
CEC055
Connecting the USB cable to the Gigabit Ethernet board USB port
Connect the smaller connector of the USB cable to the USB port of the Gigabit Ethernet board.
4. Connecting the Printer
72
4
