Ricoh Aficio SP 5200DN Hardware Guide

5. Configuration
This chapter explains supported network connections, and settings for the IP addresses and the Wireless
LAN security.
Ethernet Configuration
• Configure the printer for the network using the control panel.
• The following table shows the control panel settings and their default values. These items appear in
the [Network] under [Host Interface] menu.
Setting Name Default
Machine IPv4 Address
• Auto-Obtain (DHCP): On
• IPv4 Address: 11.22.33.44
• Subnet Mask: 0.0.0.0
• Gateway Address: 0.0.0.0
IPv6 Stateless Setting Active
IPsec Inactive
NW Frame Type Auto Select
Effective Protocol
• IPv4: Active
• IPv6: Inactive
• NetWare: Inactive
• SMB: Active
• AppleTalk: Inactive
Ethernet Speed Auto Select
IEEE802.1X Auth.(Ethernet) Inactive
Restr.IEEE802.1X Auth.Def. -
LAN Type Ethernet
Permit SSL/TLS Comm. Ciphertext Priority
75
5
