Ricoh Aficio SP C231SF Service Manual

Electrical Components
M018/M019 4-58 SM
4.11.13 EEPROM
 Replacement and Reinstallation procedures for the EEPROM are included in the
"EGB (Engine Board)" replacement procedure. Refer to "EGB (Engine Board)" for
details.
When replacing an old EEPROM with a new EEPROM, EEPROM setting is required. Follow
the EEPROM setting procedure described below.
Be sure to set the PnP Name as described in PnP Name Procedure.
Replacement Procedure
 Do the following steps 1 to 14 with the front cover of the machine open. After
completing these steps, turn off the machine.
1. Open the front cover and turn ON the machine.
 The machine may issue an error code (because the cover is open), but continue
this procedure.
2. Enter the following keys consecutively in order to enter "Engine Maintenance" in the
"Maintenance Mode Menu".
3. Select "Init Engine EEPROM" item and execute it to initialize the EEPROM.
4. Press the "Clear/Stop" key to exit the "Engine Maintenance" menu.
5. Select the "Serial No." item, and then input a serial number.
 Ask your supervisor about how to access the serial number input display.
6. Exit the serial number input display, and then enter "Engine Maintenance" again.
7. Select "Destination", and then select a destination.
8. Select "Model", and then select a model.
9. Select "PnP Name", and then select a plug and play name.
10. Select "LSU Adjustment", and then input the LSU (laser optics housing unit) setting
values.
11. Turn OFF the machine.
12. Turn ON the machine with the front cover open.
13. Enter "Engine Maintenance" in the "Maintenance Mode Menu" again.
14. Close the front cover.
15. Select "Trans. Belt Adjust", and then execute "Trans. Belt Adjust" to adjust the ITB
(Image Transfer Belt) unit.
16. Select "Fuser SC Detect", and then select "ON" or "OFF" for the consecutive fusing jam
detection.
⇒
Rev. 02/03/2010
