5. Intermediate transfer unit
If the following message appears on the control panel, replace the intermediate transfer unit:
• "Replacemnt Requird:IntTrans"
6. Waste toner bottle
Collects toner that is wasted during printing.
If a message prompting you to replace it appears on the display, replace the waste toner bottle.
• " Waste Toner Bottle full"
7. Transfer roller
If the following message appears on the control panel, replace the transfer roller, which is included with the
intermediate transfer unit:
• "Replacemnt Requird:IntTrans"
Replace the transfer roller and the intermediate transfer unit together.
8. LED heads
Clean the LED heads if black or color lines appear on prints.
9. Black drum unit / Color drum units
The drum units are installed in the order of black (K), cyan (C), magenta (M), and yellow (Y). Replace the
relevant black drum unit/color drum units when the following message appears:
• "Replacmnt Requird:PCU:Black"
• "Replacmnt Requird:PCU:Color"
10. knob
If you cannot pull out jammed paper, remove it by turning the knob.
1. Getting Started
14
