Ricoh Aficio SP C730DN User Manual

8. Optional interface board slot
Optional interface boards can be inserted.
Insert an optional wireless LAN interface board or IEEE 1284 interface board.
9. USB port B
Use a USB cable to connect the printer to a computer.
10. Ethernet port
Use a network interface cable to connect the printer to a network.
Interior
1
3
2
4
5
6
7
98
10
CSJ230
1. Toner
Loads from the printer rear, in the order of black (K), cyan (C), magenta (M), and yellow (Y).
If the following message appears on the control panel, replace the toner cartridge:
• " Out of toner"
• " Add Toner"
2. Inner cover
Open this cover when replacing the black drum unit/color drum units.
3. Inner cover open lever
Pull this lever to open the inner cover.
4. Fusing unit
If the following message appears on the control panel, replace the fusing unit:
• "Replacmnt Rqrd:Fusing Unit"
Guide to Names and Functions of Components
13
