Ricoh Aficio SP C730DN

4. Pinch the end guide and slide it inward to match the standard size.
CSJ253
5. When loading paper into Trays 2 to 4, slide the two switches at the bottom of the tray
according to the thickness of the paper.
CSJ168
If the paper is 164 g/m
2
(44 lb.) or thicker, slide both switches into the rear (thick) position. If the
paper is lighter than 163 g/m
2
(43 lb.), slide both switches into the forward (thin) position.
6. Fan the paper before loading it in the tray.
CBK254
7. Load the new paper stack print side up.
Make sure paper is not stacked higher than the upper limit (upper line) marked inside the tray.
2. Loading Paper
32
