Cleaning the Printer
69
C
Clean the registration roller by appl
ying a soft damp cloth while turning
it.
❒
Do not use c
hemical cleane
rs or organi
c solvents such
as thinners or
ben-
zene.
❒
Do not touch the belt of the tran
sfer unit an
d transfer roller .
D
Carefully clos
e the front cove
r (A).
E
Plug in the power cable, and then turn on the power.
