If you are using the camera for the first time, read this section.
Rear View
1
16
15
17
87
9
10
11
12
13
14
2
2
3
4
5
6
Item Name Refer to
1 Picture Display P.18
2 Strap Eyelet P.14
3 Terminal Cover
P.97, 105, 113, 115
4 Speaker P.67
5 USB Terminal P.105, 113, 115
6 AV Output Terminal P.97
7
N ( Macro)
P.30
8 ADJ./OK Button
(
*
)
P.46
9
F ( Flash)
P.31
10
6 ( Playback) Button
P.34
11 MENU Button P.54, 58, 62, 71, 85, 98
12 Fn (Function) Button P.48
13
t ( Self-timer)/D ( Delete) Button
P.32, 37
14 DISP. Button P.36, 40, 42
15 Power (DC input) Cable Cover —
16 Battery/Card Cover P.135
17 Tripod Screw Hole P.130
(
*
)
Instructions in this manual to “Press the ADJ./OK button !"NF”
indicate that you should press the ADJ./OK button in the up, down, left
or right direction. Instructions to “Press the ADJ./OK button” indicate
that you should press directly down on the button.
