Installation Requirements
D117/D118 2-2 SM
2.1.3 MACHINE SPACE REQUIREMENTS
ï‚§ This machine, which uses high voltage power sources, can generate ozone gas. High
ozone density is harmful to human health. Therefore, the machine must be installed in a
well-ventilated room.
A: Over 70 mm (2.8 ") (Base machine) / 120 mm (4.7 “) (with 1-bin tray unit)
B: Over 100 mm (3.9 ")
C: Over 420 mm (16.5")
D: Over 420 mm (16.5")
Put the machine near the power source with the clearance shown above.
