2.1.4 MACHINE DIMENSIONS
[A]: 621 mm [D]: 150 mm
[B]: 540 mm [E]: 505 mm
[C]: 150 mm [F]: 498 mm
2.1.5 POWER REQUIREMENTS
 Insert the plug firmly in the outlet.
 Do not use an outlet extension plug or cord.
 Ground the machine.
1. Input voltage level:
 110 V, 60 Hz More than 10 A
 120 to 127 V, 60 Hz: More than 10 A
 220 V to 240 V, 50 Hz/60 Hz: More than 5 A
2. Permissible voltage fluctuation:
NA: 108 V (120 V-10%) - 138 V (127 V+8.66 %)
EU/AA: 198 V (220 V-10%) - 264 V (240 V+10 %)
Taiwan: 99 V (110 V -10%) – 121 V (110 V + 10%)
3. Do not put things on the power cord.
