16. Attach the front right cover [E] (from the accessories, not the original cover) (M3 x 10: x
1).
17. Install the scanner unit [A] (
x 5)
18. Insert the ferrite core [B] into the cover [C] (
).
19. Attach the ferrite core cover with the ferrite core to the existing ferrite core [D] (
).
 The ferrite core [B] and the ferrite core cover [C] are included in this kit.
20. Connect the connectors of the harnesses [A]. Then route the harnesses [A] and the flat cable
[B]. Finally, connect the connector of the flat cable [B] (
x 1, x 4).
