Printing > Various Print Functions > Printing Documents with an Overlay Image Superimposed (Overlay) > Creating a New Overlay Image File
Creating a New Overlay Image File
Follow the procedure below to create an overlay image file.
● You can create an overlay image file with any application.
● When an overlay image file is created using a multiple-page document, only the first page will be saved as an overlay image.
Open the file with which you want to create an overlay image file, and then open the printer properties
dialog box.
On the [Setup] tab, click [Save as Overlay Data...] in the [Job type:] list.
The [Job Type Details] dialog box appears.
In the [File name:] box, enter a file name.
● Enter a name using up to 32 characters.
● Under Windows 95/98/Me, enter a name using up to eight characters.
Click [OK].
Make the necessary settings, and then click [OK].
The printer properties dialog box closes.
● When creating an overlay image file (when [Save as Overlay Data...] is selected in the [Job type:] list), only print quality settings are
available.
Click [OK] in the [Print] dialog box.
The overlay image file is created.
● Opening from an Application
