Ricoh J011 - Carriage Unit; Overview

CARRIAGE UNIT
SM 6-5 J001/J003
Detailed
Descriptions
6.3 CARRIAGE UNIT
6.3.1 OVERVIEW
1. Carriage Unit
2. Print Head Tank
3. Air Release Valve
4. Print Head
5. Registration Sensor
1
2
3
4
5
