Ricoh J011 - Page 442

SP Tables
SM 5-7 J007/J010/J011
J007/J010
J011
1103 CHG:W1:MID:2 MID: Mj1:ID2
1105 CHG:W1:MID:3 MID: Mj1:ID3
1107 CHG:W1:MID:4 MID: Mj1:ID4
Use this SP to set the pitch width of the charge applied to the MID area of normal
paper (excluding the LE/TE) for printing in the High Speed (Draft) mode. Do this
SP when mist build-up in the MID area of the paper in use during printing in the
High Speed (Draft) mode is clogging the print head nozzles. This SP setting is
linked to the charge pitch tables (SP1200 to SP1231). The IDs are determined by
the temperature and humidity. There are 4 IDs associated with the SP numbers
listed below:
 SP1101：ID1
 SP1103：ID2
 SP1105：ID3
 SP1107：ID4
[0 to 255/0/1/0.1 mm]
Charge Width Setting Mj2: Simplex
1108 CHG:W1:EDGE:5 LE/TE: Mj2:ID1
1110 CHG:W1:EDGE:6 LE/TE: Mj2:ID2
1112 CHG:W1:EDGE:7 LE/TE: Mj2:ID3
1114 CHG:W1:EDGE:8 LE/TE: Mj2:ID4
Use this SP to set the pitch width of the charge applied to the LE/TE of any paper
in any print mode except: normal paper in High Speed (Draft) mode and glossy
paper in High Quality Mode.
Do this SP when mist build-up up near the leading and trailing edges of the
sheets is clogging the print head nozzles during printing with any paper in any
mode, except normal paper in High Speed (Draft) mode and glossy paper in High
Quality mode. This SP setting is linked to the charge pitch tables (SP1200 to
SP1231). The IDs are determined by the temperature and humidity. There are 4
IDs associated with the SP numbers listed below:
 SP1108：ID1
 SP1110：ID2
 SP1112：ID3
 SP1114：ID4
[0 to 255/0/1/0.1 mm]
1109 CHG:W1:MID:5 MID: Mj2:ID1
1111 CHG:W1:MID:6 MID: Mj2:ID2
1113 CHG:W1:MID:7 MID: Mj2:ID3
1115 CHG:W1:MID:8 MID: Mj2:ID4
Use this SP to set the pitch width of the charge applied to the MID area of any
paper in any print mode except: normal paper in High Speed (Draft) mode and
glossy paper in High Quality Mode.
