Slide 13
Connection Ports
PJ hdl
1
2
3
4
5
6
7
8
9
10
1. S-Video IN
2. Computer IN
3. HDMI 2
4. HDMI 1
5. Service port
6. PC Control (D-
sub 9 pin)
7. LAN
8. Audio Out
9. Audio IN
10. Video IN
