Ricoh MP 2014 Series Manual

Laws and Regulations
Laser Safety
This machine complies with the requirements of IEC60825-1:2007 (EN60825-1:2007) for class 1
laser product. The machine contains one InGaAlP laser diode, 645–670 nanometer wavelength. The
beam divergence angle is 24 degrees (minimum) and 34 degrees (maximum) in the vertical direction,
and 7 degrees (minimum) and 13 degrees (maximum) in the horizontal direction, and laser beams are
generated in Continuous Wave (CW) mode. The maximum output power of the light source is 12
milliwatt.
The following label is attached to the upper cover of the machine:
Caution
Use of controls or adjustments or performance of procedures other than those specified in this manual
might result in hazardous radiation exposure.
Overseas Affiliates and Noise Emission Information
In accordance with TUV “GS Symbol” requirements, details of the EU office or representative
company are given below.
Overseas Affiliates
Ricoh Europe PLC
20 Triton Street, London. NW1 3BF, United Kingdom
Noise Emission
Maschinenlärminformations-Verordnung 3. GPSGV:
Der höchste Schalldruckpegel beträgt 70 dB(A) oder weniger gemäss EN ISO 7779
Laws and Regulations
15

Ricoh MP 2014 Series Specifications

General

Functions	Print, Copy, Scan
Print Technology	Laser
Print Speed	20 ppm
Print Resolution	600 x 600 dpi
Copy Speed	20 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Supported Paper Sizes	A3, A4, A5, B4, B5
Multiple Copy	Up to 99 copies
Duplex Printing	Manual
Interface	USB 2.0
Dimensions	587 x 581 x 461 mm
Type	All in One Printer
Standard Paper Capacity	250 sheets
Operating System Compatibility	Windows, Mac
First Print Out Time	Less than 10 seconds
