Loading Paper into the Large Capacity Tray
(mainly Europe and Asia)
The LCT can hold A4 paper only. If you want to print on 8
1
/
2
× 11 or B5 JIS from the LCT,
contact your service representative.
(mainly North America)
The LCT can hold 8
1
/
2
× 11 paper only. If you want to print on A4 or B5 JIS from the LCT,
contact your service representative.
The extension unit is required to load A4 , B4 JIS , 8
1
/
2
× 14 , or 8
1
/
2
× 11 .
1. Open the top cover of the LCT.
DPZ015
2. Load paper into the paper tray with the print side up and place it against the left side of
the tray.
Do not stack paper over the limit mark.
DPZ026
3. Press the [Down] key.
The key blinks while the bottom plate is moving down.
9. Adding Paper and Toner
130
