Ricoh MP C3504 series User Manual

Step 3: Specifying access privileges for the created shared folder
If you want to specify access privileges for the created folder to allow other users or groups to access
the folder, configure the folder as follows:
1. Right-click the folder created in Step 2, and then click [Properties].
2. On the [Security] tab, click [Edit...].
3. Click [Add...].
4. In the [Select Users, Computers, Service Accounts, or Groups] window, click
[Advanced...].
5. Specify one or more object types, select a location, and then click [Find Now].
6. From the list of results, select the groups and users you want to grant access to, and then
click [OK].
7. In the [Select Users, Computers, Service Accounts, or Groups] window, click [OK].
8. In the [Groups or user names:] list, select a group or user, and then, in the [Allow] column
of the permissions list, select either the [Full Control] or [Modify] check box.
9. Click [OK].
Registering an SMB Folder
1. Press [Home] ( ) at the bottom of the screen in the center.
2. Flick the screen to the left, and then press the [Address Book Management] icon.
3. Check that [Program / Change] is selected.
4. Press [New Program].
5. Press [Change] under "Name".
The name entry display appears.
6. Enter the name, and then press [OK].
7. Press [ Next].
Basic Procedure When Using Scan to Folder
135

Ricoh MP C3504 series Specifications

General

Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Max Paper Capacity	4, 700 sheets
Automatic Duplexing	Yes
Monthly Duty Cycle	150, 000 pages
Functions	Print, Copy, Scan, Fax
Memory (Standard)	2 GB
Copy Resolution	600 dpi
Max Paper Size	A3
Print Speed	35 ppm (A4)
Scan Resolution	600 dpi
Connectivity	Ethernet, USB 2.0, Wi-Fi
Supported Paper Sizes	A3, A4, A5, B4, B5
Paper Size	A3, A4, A5, B4, B5
Scan Speed	80 ipm (black) / 80 ipm (color)
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria
Control Panel	10.1-inch Smart Operation Panel
Warm-up Time	21 seconds
Copy Speed	35 pages per minute
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS, Linux
