Ricoh MP C3504 series User Manual

5. Print
This chapter describes frequently used printer functions and operations. For information not included in
this chapter, see Print available on our website.
Quick Install
You can install the printer drivers easily from the CD-ROM provided with this machine.
Using Quick Install, the PCL 6 printer driver is installed under network environment, and the Standard
TCP/IP port will be set.
• Manage Printers permission is required to install the drivers. Log on as an Administrators group
member.
1. Click [Quick Install] on the installer screen.
2. The software license agreement appears in the [License Agreement] dialog box. After
reading the agreement, click [I accept the agreement.], and then click [Next >].
3. Click [Next >].
4. Select the machine model you want to use in the [Select Printer] dialog box.
5. Click [Install].
6. When the port setting screen appears, specify a port.
7. Configure the user code, default printer, and shared printer as necessary.
8. Click [Continue].
The installation starts.
9. Click [Finish].
When you are prompted to restart your computer, restart it by following the instructions that
appear.
10. Click [Exit] in the first window of the installer, and then take out the CD-ROM.
119

Ricoh MP C3504 series Specifications

General

Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Max Paper Capacity	4, 700 sheets
Automatic Duplexing	Yes
Monthly Duty Cycle	150, 000 pages
Functions	Print, Copy, Scan, Fax
Memory (Standard)	2 GB
Copy Resolution	600 dpi
Max Paper Size	A3
Print Speed	35 ppm (A4)
Scan Resolution	600 dpi
Connectivity	Ethernet, USB 2.0, Wi-Fi
Supported Paper Sizes	A3, A4, A5, B4, B5
Paper Size	A3, A4, A5, B4, B5
Scan Speed	80 ipm (black) / 80 ipm (color)
Mobile Printing	Apple AirPrint, Google Cloud Print, Mopria
Control Panel	10.1-inch Smart Operation Panel
Warm-up Time	21 seconds
Copy Speed	35 pages per minute
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac OS, Linux
