Ricoh MP C8002 Series

Loading Paper into the A3/11 × 17 Tray Unit
(mainly Europe and Asia)
A3/11 × 17 tray unit can hold A3 paper only. If you want to print on A4 , B4 JIS , 11 × 17 ,
8
1
/
2
× 14 , or 8
1
/
2
× 11 , contact your service representative.
(mainly North America)
A3/11 × 17 tray unit can hold 11 × 17 paper only. If you want to print on A3 , A4 , B4 JIS ,
8
1
/
2
× 14 , or 8
1
/
2
× 11 , contact your service representative.
• Check the paper edges are aligned at the right side.
1. Check that paper in the paper tray is not being used, and then pull the tray carefully out
until it stops.
CVA004
2. Square the paper and load it print side down.
Do not stack paper over the limit mark.
CVA005
3. Carefully push the paper tray fully in.
9. Adding Paper and Toner
126
