1.Detailed Descriptions
8
No.
Description
1
Upper limit sensor (S4)
2
Actuator
Conditions for tray descent
• The right cover is opened.
• Paper end is detected.
• The tray descends until the lower limit sensor (S5) turns OFF (the sensor is blocked).
No.
Description
1
Remaining paper sensor (S6) (inside lift unit)
2
Tray lift motor (M3)
3
Lower limit sensor (S5)
4
Tray
