Ricoh RT3040 - Paper Feed Sensor (S1), Paper End Sensor (S3), Upper Limit Sensor (S4), Transport Sensor (S2)

2.Replacement and Adjustment
23
Paper Feed Sensor (S1), Paper End Sensor (S3), Upper Limit
Sensor (S4), Transport Sensor (S2)
1. Remove the upper cover. (Upper Cover)
2. Remove the paper feed unit [A] ( ×4, ×1, ×2).
3. Remove the paper feed unit cover [A] ( ×5).
