3. Adjust the side guides to the envelope width.

DSG214

4. Open the rear cover.

DSG215

5. Lower the levers for printing envelopes on both sides to the position indicated with an

envelope mark.

DSG216

Make sure to pull up the levers back to their original positions after printing.

6. Close the rear cover.

• Be sure to load envelopes so that their flaps are on the left. If you do not, the envelopes will

become creased.
