Ricoh SP 325DNw User Manual

7. Configuring Network Settings Using
OS X
This chapter describes how to connect the machine to the network and specify the network settings using
OS X.
Configurations differ according to the communication environment of your system.
Connecting the Machine to a Wired Network
The following procedure is explained using OS X 10.11 as an example.
Using a USB Cable
1. Turn on your computer.
2. Insert the provided CD-ROM into the CD-ROM drive of the computer.
If your computer does not have a CD-ROM drive, download a setup file from our website (http://
www.ricoh.com/printers/sp310/support/gateway/).
3. Double-click the CD-ROM drive icon.
4. Double-click the [Mac OS X] folder.
5. Double-click the folder of driver you want to install.
6. Follow the instructions in the setup wizard.
7. Click [Close] in the [Summary] dialog box.
8. Start System Preferences.
9. Click [Printers & Scanners].
Check that the machine automatically recognized by plug-and-play appears in the printers list.
10. Click the [+] button.
If [Add Printer or Scanner...] appears, click it.
11. Click [Default].
12. Select the printer that has "USB" indicated in the [Kind] column.
13. Select the printer you are using from the [Use:] pop-up menu.
14. Click [Add].
15. Click [Duplexer] on the [Setting up] screen, and then click [OK].
16. Quit System Preferences.
Setup is completed.
103

Ricoh SP 325DNw Specifications

General

Color	No
N-up printing	2, 4, 6, 9, 16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Manual
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Printing colors	Black, White
Maximum duty cycle	35000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Total input capacity	250 sheets
Total output capacity	125 sheets
Paper tray media types	-
Paper tray media weight	52 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
Internal memory	128 MB
Maximum internal memory	- MB
Sound pressure level (printing)	65.8 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	120 W
Power consumption (printing)	890 W
Package depth	486 mm
Package width	559 mm
Package height	386 mm
Package weight	15000 g
Cables included	AC
Server operating systems supported	Windows Server 2012 x64
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Y

Weight and Dimensions

Depth	392 mm
Width	376 mm
Height	262 mm
Weight	12300 g
