Ricoh SP 325DNw User Manual

8. Slide the print cartridge in horizontally. When the cartridge can go no further, raise it
slightly and push it fully in. Then push down on the cartridge until it clicks into place.
DSG219
9. Using both hands, carefully push up the front cover until it closes.
• When closing the front cover, push the upper area of the cover firmly. After closing the cover,
check that the error is cleared.
Removing Jammed Paper from the Bypass Tray
1. If paper is jammed in the bypass tray input area, remove the jammed paper carefully.
DSG225
2. Close the bypass tray.
Clearing Misfeeds
85

Ricoh SP 325DNw Specifications

General

Color	No
N-up printing	2, 4, 6, 9, 16
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Manual
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Printing colors	Black, White
Maximum duty cycle	35000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6
Total input capacity	250 sheets
Total output capacity	125 sheets
Paper tray media types	-
Paper tray media weight	52 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
Internal memory	128 MB
Maximum internal memory	- MB
Sound pressure level (printing)	65.8 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	120 W
Power consumption (printing)	890 W
Package depth	486 mm
Package width	559 mm
Package height	386 mm
Package weight	15000 g
Cables included	AC
Server operating systems supported	Windows Server 2012 x64
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Y

Weight and Dimensions

Depth	392 mm
Width	376 mm
Height	262 mm
Weight	12300 g
