Exterior: Rear view
1. Ventilation holes
Prevent overheating.
2. Power connector
Connect the power cord to the printer. Insert the other end into an electrical outlet.
3. Rear cover open lever
Pull this lever to open the rear cover.
4. Rear cover
Open to access the inside of the printer.
Open here to replace the fusing unit or using the envelope lever.
5. USB port B
Use a USB cable to connect the printer to a computer.
6. Ethernet port
Use a network interface cable to connect the printer to a network.
1. Getting Started
12
