Ricoh SP C340DN User Manual

Message Cause Solution
"User auth. already exists." The same account name is
already used in the newly
selected domain or server in an
environment using LDAP
Authentication or Integration
Server Authentication.
Contact your user administrator.
Message Cause Solution
"98: Error" The printer could not access the
hard disk correctly.
Turn the main power switch off
and then back on again. If the
message appears frequently,
contact your service
representative.
"AN: A job via the network
that was not printed exists
because an error occurred.
It was stored as a job not
printed."
Jobs with errors were stored
because an error occurred with a
print job via the network while the
error job storing function was
enabled.
Contact your administrator to
check whether the machine is
connected correctly to the
network.
"Address Book is currently in
use by another function.
Authentication has failed."
The printer currently cannot
perform authentication because
the Address Book is being used
by another function.
Wait a while, and then retry the
operation.
"Auto-registration of user
information has failed."
Automatic registration of
information for LDAP
Authentication or Windows
Authentication failed because the
Address Book is full.
For details about automatic
registration of user information,
see Security Guide.
"Classification Code is
incorrect."
The classification code has not
been entered, or the classification
code has been entered
incorrectly.
Enter the correct classification
code.
3. Troubleshooting
82

Ricoh SP C340DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	13.5 s
Print speed (black, normal quality, A4/US Letter)	- ppm
Duplex print speed (black, normal quality, A4/US Letter)	25 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	75000 pages per month
Number of print cartridges	-
Page description languages	PCL 5c, PCL 6, PostScript 3
Total input capacity	600 sheets
Total output capacity	150 sheets
Maximum input capacity	1100 sheets
Paper tray media types	Coated paper, Labels, Plain paper, Pre-Printed, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Security algorithms	SNMP, SSL/TLS
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor family	Intel Atom®
Sound power level (standby)	31 dB
Sound pressure level (printing)	65 dB
Display	LCD
Product color	Gray
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1300 W
Power consumption (standby)	0.5 W
Power consumption (printing)	- W
Power consumption (PowerSave)	65 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	30 - 40 °C
Storage relative humidity (H-H)	0 - 80 %
Cables included	AC

Weight and Dimensions

Depth	480 mm
Width	400 mm
Height	387 mm
