声明：本说明书著作权归杭州睿登科技有限公司所有，未经允许任何单位或个人不得用于商业用途。
25
DF: Synchronize System Time
DG: Output Current Preset value
DH: Output Voltage Preset value
CX: Actual Output Voltage
CY: Actual Output Current
4.3.1 Basic Functions
PC software operation video: https://youtu.be/mjt1RMaah1Y
The basic functions of PC software: voltage/current preset, data group quick call
out, calibration fine tuning, brightness setting, voltage and current curve exporting.
You can rotate the wheel or enter the value to set the voltage and current, the graph
above the button shows the real-time voltage and current curve. You can zoom in
and out the curve by using the mouse wheel, double click the curve to auto adjusts
the axis, you can right click on the curve to clean the curve or export the curve data
to picture or excel.
4.3.2 Calibration
The calibration fine-tuning function needs to be operated by a professional
electronic person who has more than five and a half multimeter. It will change the
system setting, incorrect operation may exceeds the hardware limit and cause
damage, and the resulting damage is not covered by the warranty! The limit error of
the product is generally much smaller than the nominal error, when the error is close
to or even higher than the nominal error, you need to check if the measuring
instrument is accurate.
RD6006 calibration operation video: https://youtu.be/c9sn1wY2mjE
Click “Calibration” and enter the password “168168”, you can enter the
Calibration Fine Tuning page (if you enter the password, by default you have
accepted the above red letter agreement). It can read the calibration data after
connection; click the arrow to fine tuning the data. According to the linear function
y=kx+b, the constant b is equivalent to the zero value, the slope k is equivalent to the
proportional value, adjust this two values so that the data will be close to the real
test value.
Set the output voltage at 1V, adjust the output voltage zero point to make the
multimeter display close to 1V, and then set the output voltage at 30V, adjust the
output voltage proportional value to make the multimeter display close to 30V. In the
same way you can set 0.1A and 3A output current to calibrate the zero point and
proportional value of the output current.
Set the output voltage at 1V and calibrate the actual output voltage zero point to
make the actual output voltage displayed on RD6012 close to the value on
multimeter. You can set 30V and calibrate the proportional value of actual output
voltage. In the same way you can set 0.1A and 3A to calibrate the zero point and
proportional value of the actual output current. (This section does not provide
