PAGE 10
CTCSS/DCS DECODE SETUP
Channel operation refers to a temporary change on a current channel function. Once the
radio is turned off or switched to another channel, the temporary change will be erased. Under
frequency+channel mode, channel+Name Tag mode or VFO mode, the operating methods are as
follows:
1. After pressing the “(FUNC) BUTTON”, the top left corner of LCD displays an F icon, then press
“(8SET) BUTTON” to enter function menu.
2. Press “UP ARROW” or “DOWN ARROW” button to choose the desired function to be set.
3. Press “(FUNC) BUTTON” to enter into function menu setup.
4. Press “UP ARROW” or “DOWN ARROW” button to choose the desired contents to be set.
5. Press “(FUNC) BUTTON” to return to upward menu.
6. Press “(ESC/M) BUTTON”or “(
*
ENT) BUTTON” to conrm and exit.
NOTE: When transceiver works in professional transceiver mode, operation pressing “(FUNC)
BUTTON” followed by “(8SET) BUTTON” is not valid. Under frequency mode (VFO), once the radio
is turned off or changed to new VFO frequency, the channel operations setting will be remained until
next change.
CHANNEL OPERATIONS
If this function is enabled, you shield your radio from other transceivers of same frequency.
1. After pressing the “(FUNC) BUTTON”, the top left corner of LCD displays an F icon, then press
“(8SET) BUTTON” to enter function menu.
2. Press “UP ARROW” or “DOWN ARROW” button to choose No.1 function item. It shows “R-CDC”
on LCD
3. Press “(FUNC) BUTTON” to enter into function menu setup.
4. Press “(1FM) BUTTON” to choose CTCSS, DCS or OFF. When DCS signaling is selected, press
“(
*
T/R) BUTTON” to choose DCS positive and inverse code.
5. Press “UP ARROW” or “DOWN ARROW” button to choose the desired CTCSS / DCS encodes
signaling.
6. CTCSS: 67Hz- 254.1Hz, 50 groups in total, Default: 67Hz.
7. DCS: 017N-765I, 232 groups in total. “N” stands for positive code, “I” Stands for reverse code.
8. Press “(FUNC) BUTTON” to go back to previous menu. Press “(ESC/M) BUTTON”or “(
*
ENT)
BUTTON” to conrm and exit.
CTCSS/DCS ENCODE SETUP
1. After pressing the “(FUNC) BUTTON”, the top left corner of LCD displays an F icon, then press
“(8SET) BUTTON” to enter function menu.
2. Press “UP ARROW” or “DOWN ARROW” button to choose No.2 function item. It shows “T-CDC”
on LCD
3. Press “(FUNC) BUTTON” to enter into function menu setup.
4. Press “(1FM) BUTTON” to choose CTCSS, DCS or OFF. When DCS signaling is selected, press
“(
*
T/R) BUTTON” to choose DCS positive and inverse code.
5. Press “UP ARROW” or “DOWN ARROW” button to choose the desired CTCSS / DCS encodes
signaling.
6. CTCSS: 67Hz- 254.1Hz, 50 groups in total
