PAGE 28
General
Frequency Range UHF: 476.4250-477.4125MHz
Channel Capacity 80 channels
Phase-locked Step 5KHz, 6.25KHz
Operating Voltage 7.4 DC ±20%
Battery Life More than 12 Hours (1200mAh), by 5-5-90 work cycle
Frequency Stability
Operating Temperature
±2.5ppm
-20~ +55℃
Size 195×56×30mm (with battery pack, no antenna)
Weight 185 g (with battery pack, no antenna)
Receiving Part
Narrow band
Sensitivity(12dB SINAD) ≤0.35μV
Adjacent Channel Selectivity ≥60dB
Intermodulation ≥60dB
Spurious Rejection ≥80dB
Audio Response 6dB / per interval
Hum & Noise ≥ 45dB
Audio Distortion ≤5%
Audio Power Output 500mW (at 10%)
Transmitting Part
Modulation 11KΦF3E
Adjacent Channel ≥60dB
Hum & Noise ≥40dB
Spurious Emission ≤－36dB
Audio Response 6dB / per interval
Audio Distortion ≤5%
TECHNICAL SPECIFICATIONS
