RIDGID JP0600 - Page 37

37
Repair Parts
Parts List for RIDGID 6-1/8" Jointer/Planer
Model No. JP06000
RIDGID parts are available on-line at www.ridgidparts.com
Figure 1
Always order by Part Number - Not by Key Number
* Standard hardware item, may be purchased locally
† These replacemet parts are available where you pur-
chased your jointer.
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
826655
824854-1
824867
824866
*
824868
824865
*
824856
160033-4
*
824859
824860
824858
*
824861
826524
*
*
*
141594-13
824853-1
Guard Cutter
Table Infeed
Knob
Retainer Knob
Screw Pan Hd 8/32 x 5/8
Spring
Retainer
Screw Pan Hd M5 x 0.8-10
Gib
Screw Set 1/4-20 x 1
Nut Hex 1/4-20
Screw Elevation
Washer Brass
Clamp
Screw Set 1/4-20 x 3/8
Collar
Handwheel
Washer 17/64 x 5/8 x 1/32
Screw Pan Hd 1/4-20 x 1/2
Lockwasher 8mm
Screw Cap 5/16-18 x 1-1/4
Base
Key
No.
Part No. Description
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
824853-1
824871-1
*
826529
824873
824872
824874
824857
824855-1
824862-1
824863
*
813249-106
824864
AC8601
820632-2
824925
824926
826523
SP6173
826644
824082
Base
Block Stop Pin
Screw Cap 5/16-18 x 3/4
Knob Plunger
Housing Plunger
Spring
Plunger
Screw Wing 1/4-20 x 1
Table Outfeed
Holder
Washer 3/8 x 20mm x 3mm
Screw Hex Hd 3/8-16 x 1-1/4
Pin Roll 4mm x 20mm
Key
†Push Block
Ring, Retaining
Gauge, Knife
Rod Knife Gauge
Knob Outfeed
Owners Manual
Pointer
Screw Pan Hd. 3/16-24 x 1/4
