Repair Parts
Parts List for RIDGID 6-1/8" Jointer/Planer
Model No. JP06000
RIDGID parts are available on-line at www.ridgidparts.com
Figure 2
Always order by Part Number - Not by Key Number
* Standard hardware item, may be purchased locally
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
824895-1
102817
826527
824899
824896
*
*
820632-3
824894
*
*
824921-1
824889
826643
Slide Fence
Screw Set Dog Point 1/4-20 x 1/2
Knob
Rod Knob
Knob, Nut
Nut Hex 3/8-16
Washer 3/8 x 3/4 x 3/32
Ring Retaining 6mm
Rod Bevel Lock
Screw Pan Hd 1/4-20 x 1/2
Washer 17/64 5/8 x 1/32
Guard Rear
Bracket Trunnion
Pointer
Key
No.
Part No. Description
15
16
17
18
19
20
21
22
23
24
25
26
27
824082
824884
824893
824882-1
*
*
*
*
*
*
*
824898
824897
Screw Pan Hd 3/16-24 x 1/4
Trunnion
Nut Bevel Lock
Fence
Washer 5/16
Screw Hex Hd 5/16-18 x 5/8
Screw Hex Hd 5/16-18 x 1
Nut Hex 5/16-18
Screw Hex 5/16-18 x1-3/4
Nut Hex 1/2-20
Washer 1/2 x 1-1/8 x 3/32
Bolt Clamp
Shaft Lock
