Repair Parts
Parts List for RIDGID 6-1/8" Jointer/Planer
Model No. JP06000
RIDGID parts are available on-line at www.ridgidparts.com
Figure 3
Always order by Part Number - Not by Key Number
* Standard hardware item, may be purchased locally
Key
No.
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
826522
*
826658
826639
826645
826659
826647
*
826680
*
803835-1
Chute Dust
Screw Wing 1/4-20 x 5/8
Screw Pan Cr Serr 3/16-24 x 3/8
Panel Left Side
Panel Top
Guard Pulley
Stiffener Rear
Lockwasher 10mm
Stud Mounting
Nut Hex 3/8
Foot Leveling
Key
No.
Part No. Description
12
13
14
15
16
17
18
19
20
21
826646
*
826648
See Fig. 5
*
*
826649
826652
824909
826650
Stiffener Front
Bolt Hex 5/16-18 x 3/4
Bracket Motor
Motor Asm
Washer 5/16
Nut Hex 5/16-18
Panel Front
Panel Right Side
Grommet
Panel Rear
