RIDGID SP6263 - Page 77

77
Repair Parts
Key
No
Part No. Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
821217
827948
805552
815865
828695
808447-6
827919
274865
820521
820515
161255-6
805552
815815
820517
809491-1
820512
824159
Screw, Guard Clamp
Link, Pull
* Washer, 17/64 x 5/8 x 1/16
Screw, Hex Washer Hd Type
"TT" 1/4 - 20 x 1/2
* Screw, Pan Shoulder Type "TT" 10-32
Spacer #10 x .125
Washer, Spring
Knob, 5/16-18
* Washer 21/64 x 5/8 x 1/16
Spacer
Knife, Riving
* Nut, Lock 1/4-20
* Washer 17/64 x 5/8 x 1/16
Pawl, AKB
Bushing
*Screw,PanHd.1/4-20x1
Holder, AKB
Screw, Flat Hd Type “TT” 1/4 - 20 x 9/16
PARTS LIST FOR RIDGID 10" RADIAL SAW
MODEL NUMBER RS10000
Always order by Part Number - Not by Key Number
Figure 4 - Guard
Key
No.
Part No. Description
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
820519
114604
820530
808822-1
820532
809019-4
820632-3
809019-5
820985
808380
805548-10
824161-1
820524-1
820531
821218-1
60413
828139
821449
827916
Nut, Slotted 1/4 - 20
* Lockwasher 1/4
Support, Knife
Nut, Push 1/4
Bolt
Bolt, Rd Hd Short Neck 5/16 - 18 x 1-3/4
* Ring, Retaining
* Bolt, R.H. Short Neck 5/16 - 18 x 5/8
Lower, Inner Guard
Screw Plastite #8-16 x 1/2
Washer 3/16
Guard
Link
Guard, Lower
Hold Down
Nut, Push 5/16
Elbow, Dust
Nut, Square 5/16 - 18 Double
Strap-Retainer
* Standard Hardware Item - May Be Purchased Locally
