RIDGID Table Saw - Page 64

64
Repair Parts
Parts List for RIDGID 10 Inch Table Saw
Model No. TS24001
RIDGID parts are available on-line at www.ridgidparts.com
Figure 5 - Guard Assembly
Always Order by Part Number - not by Key Number
* Standard Hardware Item - May be purchased locally
1
2
3
4
5
8
11
12
7
10
6
9
8
13
15
16
17
21
22
2
3
14
4
19
4
5
4
17
18
18
20
Key
No.
Part No. Description
–
1
2
3
4
5
6
7
8
9
10
827499
62519
827646
827648-1
805549
60012
827649-1
62390
802612
826466
827536
Guard Complete
Spring, Pawl
Spacer, Pawl
Pawl
*Washer,
13/64 x 9/16 x 1/32
Nut Lock 10-32
Support, Guard
Pin Guard 1/4 x 1-3/4
Nut Push 1/4
Guard w/Label
Spreader Blade
Key
No.
Part No. Description
11
12
13
14
15
16
17
18
19
20
21
22
803422-163
827541
827877
62636
827511
805461-7
114604
37937
806214-3
179793
806214-4
827647
Pin, Roll 3/16 x 15/16
Support Spreader
Mount Spreader
Nut Square 1/4-20
Knob Guard
Screw Hex Hd 1/4-20 x 1
* Lockwasher Ext 1/4
* Washer 17/64 x 5/8 x 1/32
Screw Soc Cap 10-32 x 7/8
* Screw Hex Hd 1/4-20 x 5/8
Screw Soc Cap 10-32x1-1/2
Spacer Support
