What does it mean if my Riello UPS display shows the code A13?
If the display shows the code A13, it indicates that the protection device upstream from the bypass line is open (only if bypass is separate) or the bypass isolator is open. Restore the protection device upstream, checking that there is no overload or short circuit at the output of the UPS. Otherwise, close the isolator (SWBYP only if bypass is separate).
How to fix Riello UPS that doesn't switch to standby mode?
If the Riello UPS connected to the mains does not switch to stand-by mode, it could be due to a missing connection to the input terminal. Connect the mains to the terminals following the indications in the paragraph on Installation. It could also be that the 1/0 switch is set to 0, so set the switch to 1. Another possibility is that the isolator (SWIN) is open, so close the isolator. If mains power is missing (blackout), make sure the mains power is present and if necessary, perform battery start-up to power the load. Finally, it could be the intervention of the upstream protection device, so restore the protection, but first make sure there is no overload or short circuit on the UPS output.
What to do if no power reaches the load from Riello UPS?
If no power reaches the load from your Riello UPS, first check the connection to the output terminal and connect the load to the terminals. If the UPS is in stand-by mode, run the start-up sequence. If the STAND-BY OFF mode has been selected, change the operating mode, since the STAND-BY OFF (emergency) mode only powers the loads when a black out occurs. If there is a malfunction of the UPS and automatic bypass is out of use, insert the maintenance bypass (SWMB) and contact the nearest service centre.
What does code A26 mean on my Riello UPS display and how do I fix it?
If the display of your Riello UPS shows the code A26, it indicates that the battery fuses are blown or the fuse holder isolators are open. Replace the fuses or close the isolators (SWBATT). If necessary, replace the fuses with others of the same type.
What does it mean if my Riello UPS display shows the code A39?
If the display shows the code A39, the batteries have failed the periodic efficiency test. It is recommended to replace the batteries of the UPS, since they are no longer able to maintain the charge for a sufficient autonomy. The replacement of the batteries must be carried out by qualified personnel.
What does it mean if my Riello UPS display shows one or more of the following codes: F03, F04, F05, A08, A09, A10?
If the display shows codes F03, F04, F05, A08, A09, or A10, it could be due to a missing connection on one or more phases (only for TM version) or the switch position on the rear of the UPS is incorrect (only for TM version). With the three-phase connection the switch must be in position “? 3~”. Check the connection of Phase 2 and Phase 3. With the single-phase connection the switch must be in position “? 1~”. Check the position of the switch selector. Internal protection fuses on the phase or on the input relay broken need qualified support.
What does L11 error code mean on Riello UPS?
If the display of your Riello UPS shows the following code L11, it indicates a static bypass rupture or fault. Activate the maintenance bypass (SWMB) if present. Turn the UPS off and back on again. Exclude the maintenance bypass and if the problem persists, contact the nearest service centre.
What to do if no power reaches the load connected to my Riello UPS?
If no power reaches the load, check the connections to the output terminal and ensure they are properly connected. If the UPS is in stand-by mode, run the start-up sequence. If the STAND-BY OFF mode has been selected, change the operating mode, as this mode only powers the loads during a blackout. If the UPS has malfunctioned and the automatic bypass is out of use, insert the maintenance bypass (SWMB) and contact the nearest service center.
What to do if Riello UPS shows A30 or A32 and won't start?
If the display of your Riello UPS shows one or more of the following codes: A30, A32 and the UPS does not start up, it could be because the ambient temperature is below 0°C. Heat the environment, wait for the heat sink temperature to rise above 0°C and then start up the UPS. It could also be a fault in the heat sink temperature probe. Activate the maintenance bypass (SWMB) if present, turn the UPS off and back on again and exclude the maintenance bypass. If the problem persists, contact the nearest service centre.
What does U06 error code mean on Riello UPS?
If the display of your Riello UPS shows the following code U06, it means that the batteries are discharged and the UPS is waiting for the battery voltage to exceed the set threshold. Wait for the batteries recharging or force start-up manually.
General| Power Rating | 5000 VA |
|---|---|
| Input Voltage | 220/230/240 V |
| Output Voltage | 220/230/240 V |
| Output Power Factor | 0.9 |
| Technology | On-line double conversion |
| Communication Ports | USB, RS232 |
| Communication Interface | USB, RS232 |
| Operating Temperature | 0-40°C |
| Input Voltage Range | 160-276 V |
| Frequency Range | 50/60 Hz |
| Waveform | Sinewave |
| Battery Type | Sealed Lead Acid |
| Battery Runtime | Varies based on load |
| Typical Backup Time at Full Load | 5 minutes |
| Typical Recharge Time | 4 hours |
| Relative Humidity | 0-95% non-condensing |
Step-by-step guide for replacing battery packs.
Lists configurable functions and their default settings.
Table of common issues, causes, and resolution steps.
Explanation of various error and status codes displayed by the UPS.
Comprehensive specifications for UPS models and battery boxes.
